Clean-Cuts™ Precision Cutting Non-Ferrous (PCNF)

Clean-Cuts™ Precision Cutting Non-Ferrous (PCNF)

Typical sizes are (but not limited to) 20″ – 28”.

Usually used on plate saws for an exacting finish and tight tolerances.  Typical sizes are (but not limited to) 20″ – 28”. Also in metric sizes:  500mm – 720 mm, with appropriate tooth counts for the application. Saws include MetlSaw, Schelling, and Briganto (to name a few) to cut plate thicknesses from 1/4″ – 14″. Specialty Saw manufactures industrial carbide-tipped circular saw blades from 10” – 88” which run on a variety of saws and systems. Our broad industrial production experience includes all aspects of metal production from casting billets and cakes to extruding shapes and profiles, to cutting plates in metal service centers through to extrusion profile cut-offs and machining systems.

With over sixty-eight years of experience, we can readily advise and design which blade profiles and production recipes will run best with which non-ferrous alloy and at what feed rates. Our experience also encompasses saw set-up and inspection, to ensure that optimal cutting performance is achieved for maximum blade life to guarantee consistent cutting and operating costs. We cut both hot and cold materials depending on the application or the production line. Our knowledge of saw requirements will allow you to get the best out of your production equipment.

  • Best Micro-Finish
  • Longest Life
  • Quiet Cutting

Sawing Applications:

  • Plate Saws
  • Bar Cut-Off Saws
  • Sheet Saws

Plate Saw Machines:

  • MetlSaw
  • Schelling
  • Briganto

Materials:

  • Aluminum 6000, 7000, 1100, 3000, 2000, 4000 series
  • Bronze
  • Brass

Professional Engineering Services

No-Cost Inspection

A blade is no better than the saw it is on and how well they are engineered to work together.

Specialty Saw, Inc. provides those engineering services to each of its customers. This includes a “no-cost inspection” of each of their sawing operations including a written survey report with an eye toward best practices, safety, and operator training.

Just call us at 1-800-225-0772 or e-mail us at info@specialtysaw.com and we will make an appointment to come out to see you.

Carbide-Tipped Saw Blades

PCNF (Precision Cutting Non-Ferrous) Carbide Tipped Blades for Plate Saws

20″ – 30″ (780 MM) Diameter

Model Diameter Teeth Material Thickness
PCNF2048 20″ 48 3″-4″
PCNF2060 20″ 60 2″-3″
PCNF2072 60 72 1″-2″
PCNF2084 60 84 0.5″-1″
PCNF52048 520MM 48 3″-4″
PCNF52060 520MM 60 2″-3″
PCNF52072 520MM 72 1″-2″
PCNF52084 520MM 84 0.5″-1″
PCNF2248 22″ 48 4″-5″
PCNF2260 22″ 60 3″-4″
PCNF2272 22″ 72 2″-3″
PCNF2284 22″ 84 1″-2″
PCNF2448 24″ 48 5″-6″
PCNF2460 24″ 60 4″-5″
PCNF2472 24″ 72 3″-4″
PCNF2484 24″ 84 2″-3″
PCNF62048 620MM 48 5″-6″
PCNF62060 620MM 60 4″-5″
PCNF62072 620MM 72 3″-4″
PCNF62084 620MM 84 2″-3″
PCNF68048 680MM 48 6″-7″
PCNF68060 680MM 60 5″-6″
PCNF68072 680MM 72 4″-5″
PCNF68084 680MM 84 3″-4″
PCNF2648 26″ 48 6″-7″
PCNF2660 26″ 60 5″-6″
PCNF2672 26″ 72 4″-5″
PCNF2684 26″ 84 3″-4″
PCNF2848 28″ 48 7″-8″
PCNF2860 28″ 60 6″-7″
PCNF2872 28″ 72 5″-6″
PCNF2884 28″ 84 4″-5″
PCNF78048 780MM 48 7″-8″
PCNF78060 780MM 60 6″-7″
PCNF78072 780MM 72 5″-6″
PCNF78084 780MM 84 4″-5″
